TimberTech Statement Rail Hollow Square Balusters Infill

TimberTech Statement Rail delivers pre-routed PVC railing reinforced with aluminum — a system built for Montana’s temperature swings and short building season. The hollow square balusters (1-1/4” x 1-1/4”) come pre-spaced in the rail system, eliminating the measuring and drilling that eats up June afternoons.

The extruded PVC won’t rot, crack, or need annual staining — claims plenty of products make, but few back with a 25-year warranty. The material resists moisture completely, preventing mold, mildew, and rot that plague wood railings in valley fog and spring snowmelt conditions.

Installation Speed and Pre-Routed Design

The pre-routed rail system changes the installation math. A 6-foot kit includes 14 balusters, while the 8-foot kit packs 18. No marking baluster locations. No drilling pilot holes. The bottom rail snaps over its aluminum reinforcement, balusters drop in, then the top rail snaps into place.

Crush blocks space at maximum 36-inch intervals to prevent rail sag under snow load. Hidden fasteners keep the finished look clean — no exposed screws collecting ice and moisture.

The system handles both level and stair applications. Stair angles from 18 to 40 degrees work with the standard components. Level sections come in actual lengths of 78 inches (6-foot nominal) and 102 inches (8-foot nominal).

Aluminum-Reinforced PVC Performance

The aluminum reinforcement inside the PVC provides the structural backbone. PVC alone would flex under load — add Montana snow and that flex becomes failure. The aluminum core maintains rigidity while the PVC exterior handles weather exposure.

UV resistance protects the white finish from fading, though elevation UV will test any material over decades. The PVC accepts 100% acrylic latex paint in light colors (LRV greater than 55) if homeowners want to change colors down the road.

Specification	Value
Baluster Dimensions	1-1/4” x 1-1/4” hollow square
Rail Heights	36” and 42”
6’ Kit Balusters	14 included
8’ Kit Balusters	18 included
Stair Angle Range	18° to 40°
Crush Block Spacing	36” maximum
Rail Cap Profile	2-3/4” graspable

The system meets IRC and IBC requirements — critical for permit approval. Testing against ICC-ES AC174 provides the paper trail inspectors want to see.

Dimensional Specifications and Compatibility

Each kit arrives complete. No hunting for compatible brackets or wondering which fasteners to use. The package includes aluminum reinforcements, mounting brackets, crush blocks, and the specific screws for each connection type.

Statement Rail works exclusively with 5” x 5” Statement PVC Post Sleeves. Don’t mix with other railing brands or fasteners — the pre-routed spacing and hidden fastener system won’t align with other manufacturers’ dimensions.

Cut the aluminum reinforcements 1/4 inch shorter than the PVC rails to allow for thermal movement. Use standard #8 x 1-1/4” screws for bracket attachment — no impact driver, which can strip the aluminum threads.

The low-maintenance promise holds weight here. No sanding rough spots every spring. No staining before the summer party. No watching the south-facing sections fade faster than the rest. The 25-year warranty covers cracking, chipping, rotting, swelling, and fading — the failures that send homeowners back to the lumberyard every few years with wood systems.

For Montana contractors juggling weather windows and labor schedules, the pre-routed system saves real hours. For homeowners tired of annual maintenance, the PVC delivers on its promises. The aluminum backbone handles snow loads wood can’t match.

Frequently Asked Questions

Q: What size balusters come with TimberTech Statement Rail kits?

TimberTech Statement Rail includes hollow square balusters measuring 1-1/4” x 1-1/4” made from extruded PVC. The 6-foot rail kit comes with 14 balusters, while the 8-foot kit includes 18 balusters, all pre-spaced in the rail system.

Q: Can TimberTech Statement Rail be used on stairs?

Yes, TimberTech Statement Rail handles stair applications with angles between 18 and 40 degrees using the standard components. The system includes both level and stair mounting brackets, with stair sections available in 6-foot (72” actual) and 8-foot (96” actual) lengths.

Q: What’s included in a TimberTech Statement Rail kit?

Each TimberTech Statement Rail kit includes the top rail cap (2-3/4” graspable profile), two common rails (top and bottom), two aluminum reinforcements, hollow square PVC balusters (14 or 18 depending on length), four mounting brackets, crush blocks, and all necessary screws (#8 x 1-1/4”, #10 x 3”, #8 x 2-1/2”).

Q: What warranty does TimberTech offer on Statement Rail?

TimberTech backs Statement Rail with a 25-year limited product warranty that covers cracking, chipping, rotting, swelling, and fading under normal use conditions. The warranty applies to the PVC components and protects against the typical failures that affect wood railing systems.

Q: Can TimberTech Statement Rail be painted?

Yes, TimberTech Statement Rail’s white PVC surface accepts 100% acrylic latex exterior paint in light colors with an LRV (Light Reflectance Value) greater than 55. The UV-resistant PVC maintains its white finish without painting, but the option exists for color changes.

Q: What posts work with TimberTech Statement Rail?

TimberTech Statement Rail is designed exclusively for use with 5” x 5” Statement PVC Post Sleeves and must be used as a complete system. The rails are also compatible with Statement Post Caps, Post Skirts, TimberTech Rail Lighting, and Gate Kits.
