AZEK Cabana X Core Model

The AZEK Cabana X Core Model delivers commercial-grade extruded aluminum frame construction in a 10’ x 10’ footprint that contractors can modularly expand in 10’ increments. This motorized pergola system handles up to 120 mph winds with required anchors and achieves Class A Flame Spread Rating and Class A Smoke Developed Index Rating — critical certifications for Montana’s wildfire-prone regions.

For contractors building in the Flathead Valley, Bitterroot, or anywhere fire risk drives material selection, those Class A ratings matter. Non-combustible extruded aluminum construction means this passes code requirements that wood pergolas can’t touch. The high snow load design addresses Montana’s winter reality, though specific PSF ratings vary by configuration.

Core Model Specifications

Specification	Value
Base Footprint	10’ x 10’
Frame Material	Commercial-grade extruded aluminum
Hardware	Stainless steel
Weight	Approximately 450 lbs (varies by finish/configuration)
Louver Count	17
Motor System	Somfy-powered
Control	Hand-held remote
Post Adjustment	0.25” increments up to 1.75”
Wind Rating	Up to 120 mph (with required anchors)
Fire Rating	Class A Flame Spread, Class A Smoke Developed Index

The premium powder-coat finish comes in six configurations: Black, White, Black frame with White louvers, White frame with Black louvers, South Beach (White frame with Teak louvers), Aspen (Black frame with Walnut louvers). That Aspen finish with walnut-grain louvers fits Montana’s timber aesthetic without the maintenance headaches of real wood.

Assembly and Installation

3D guided step-by-step instructions via the BILT app walk crews through assembly. No more squinting at paper diagrams in the wind. The adjustable post-height system (0.25” increments up to 1.75”) solves the sloped-lot problem common in Montana properties. Set the posts level even when the grade runs downhill toward the view.

Easy power-plug integration (no complex hard-wiring required for basic model) speeds installation. The Core model ships with 4 All-weather resistant powder-coated posts, 4 Structural beams, 17 Motorized adjustable louvers, Somfy handheld remote, Complete assembly kit (hardware, fasteners, power plug kit). Everything needed except the concrete footings.

Core vs Core+ Comparison

The ‘Core’ model is the base motorized version, while ‘Core+’ adds integrated lighting and smart features:

Feature	Core	Core+
LED Lighting	None (Enhancement ready)	Integrated color-changing RGB LED lights
Control	Somfy Handheld Remote	Remote and Smart App control
Connectivity	Standard Power Plug	Optional Wi-Fi hotspot integration

The Core model’s “enhancement ready” design means contractors can add lighting later without rework. Start with the base system, let the client live with it, then upgrade when they’re ready to spend more.

Modular Expansion Options

The ‘MOD’ extensions and linking multiple units capability transforms this from a single pergola into a complete outdoor room system. Compatible with ‘MOD’ extensions (canopies, slats, canvas) plus Decorative Corbels (ends), Sunbrella Curtains & Rods, Interchangeable side panels (Solid, Slat, Decorative), Power Panels (integrated power for AV equipment).

Start with one 10x10 unit over the grill. Add a second unit next year for the dining area. Link them with a connecting beam kit. The modular approach spreads costs across multiple seasons while maintaining design coherence.

Montana-Specific Advantages

That 120 mph wind rating handles chinook gusts along the Rocky Mountain Front. The Class A fire ratings meet code requirements in WUI zones across Ravalli County and the Flathead Valley. The aluminum frame shrugs off UV exposure at elevation — no fading, no maintenance, no recoating every three years like wood.

The patented interlocking louver system for weather protection keeps rain out when closed. More important in Montana: it sheds snow when angled. The motorized adjustment means homeowners can dump snow load with a button press instead of climbing a ladder with a roof rake.

For commercial projects — restaurant patios in Whitefish, resort pool areas, winery tasting spaces — the frame carries a Limited Lifetime Warranty that covers the investment. Customer reviews from hospitality projects praise the professional support and clear communication through the order process.

Bottom Line

The Cabana X Core Model costs more than stick-building a pergola. No argument there. But factor in the fire ratings, wind certification, snow-shedding capability, and zero maintenance — the math shifts. For clients who understand that crying once beats crying annually, this system delivers.

Skip it for basic shade over a concrete pad. This is overkill for that. But for elevated decks, poolside installations, commercial applications, or anywhere building codes demand certified performance, the Cabana X Core earns consideration. The modular expansion path lets contractors start small and grow the system as budgets allow.

Frequently Asked Questions

Q: What are the actual dimensions and weight of the AZEK Cabana X Core Model?

The AZEK Cabana X Core Model has a 10’ x 10’ footprint and weighs approximately 450 lbs (varies by finish/configuration). The system is modularly expandable in 10’ increments, allowing configurations like 10’x20’ or 10’x30’.

Q: What’s the difference between the Core and Core+ models?

The AZEK Cabana X Core includes motorized louvers with a Somfy handheld remote, while the Core+ adds integrated color-changing RGB LED lights and smart app control with optional Wi-Fi connectivity. Both models share the same commercial-grade aluminum frame, stainless steel hardware, and premium powder-coat finish.

Q: How does the AZEK Cabana X handle Montana’s snow loads and wind?

The AZEK Cabana X Core Model is designed for high snow loads (specific PSF varies by configuration/installation) and handles up to 120 mph winds with required anchors. The 17 motorized louvers can be adjusted to shed snow, and the system features a patented interlocking louver design for weather protection.

Q: What fire ratings does this pergola system have?

The AZEK Cabana X Core Model achieves Class A Flame Spread Rating and Class A Smoke Developed Index Rating due to its non-combustible extruded aluminum construction. These ratings make it suitable for wildfire-prone areas where wood structures may not meet code.

Q: Can I adjust the posts for uneven ground?

Yes, the AZEK Cabana X Core Model features an adjustable post-height system that allows 0.25” increments up to 1.75” for leveling on uneven surfaces. This mechanical adjustment system helps accommodate sloped lots without custom fabrication.

Q: What comes in the AZEK Cabana X Core kit?

The AZEK Cabana X Core kit includes 4 all-weather resistant powder-coated posts, 4 structural beams, 17 motorized adjustable louvers, a Somfy handheld remote, and a complete assembly kit with hardware, fasteners, and power plug kit. Assembly instructions are provided through the BILT app with 3D guided step-by-step directions.

Q: What color options are available for the AZEK Cabana X?

The AZEK Cabana X Core Model offers six color configurations: Black, White, Black frame with White louvers, White frame with Black louvers, South Beach (White frame with Teak louvers), and Aspen (Black frame with Walnut louvers). All finishes feature a premium powder-coat for durability.
